# Largest Rectangle Algorithm

#### 2020-05-02 image analysis

Most of my research deals in some way live microscopy data and the analysis thereof. As biological samples (and microscopes for that matter) tend to be unstable over time, and the samples appear to wobble around. Here is an image series where the object of interest (the white square) moves around over time:

It is often necessary to "register" image series in order to keep things in focus. There are nicely working plugins for this in FIJI/ImageJ, and the idea is that the algorithm goes through each frame and adjusts the image so that it bests matches the initial image or prevoius frame. Here is the same image series from above registred with TurboReg in FIJI:

This is certainly an improvement, since our object of interest says in place. However, we are left black edges that dance around the outside of the image. In order to get rid of the black edges, one needs to crop the image stack. For a handful of images, this is easy to do by hand, but for a lot of images, one needs an automated solution to run in batch.

I had written a little script in FIJI a while ago to do this for translation-based image registration (i.e. without rotation), where the registered part of the image remained square with vertical or horizontal images. However, I recently needed to do some rigid-body registration including rotation, and my algorithm for cropping the black edges didn't work for this.
After playing around with this for a while, I realized that what I was really trying to do was to crop out the largest possible square in the image.

As it turns out, this problem is apparently related to a really classic problem in algorithm development for finding the largest rectangle in a histogram, with an O(n) solution. After reading more about this problem and its solutions, I could write an algorithm to do this in Python that takes an image and gives the top left coordinates, width and height of the largest zero rectangle:

```import numpy as np

def find_largest_rectangle_2D(array):
"""Gets the coordinates of the largest rectangle of 1s in a 2D binary array"""

#first get the sums of successive vertical pixels
vert_sums = (np.zeros_like(array)).astype('float')
vert_sums[0] = array[0]
for i in range(1,len(array)):
vert_sums[i] = (vert_sums[i-1] + array[i]) * array[i]

#declare some variables for keeping track of the largest rectangle
max_area = -1
pos_at_max_area = (0,0)
height_at_max_area = -1
x_end = 0

#go through each row of vertical sums and find the largest rectangle
for i in range(len(vert_sums)):
positions = []  # a stack
heights = []  # a stack
for j in range(len(vert_sums[i])):
h = vert_sums[i][j]
if len(positions)==0 or h > heights[-1]:
heights.append(h)
positions.append(j)
elif h < heights[-1]:
while len(heights) > 0 and h < heights[-1]:
h_tmp = heights.pop(-1)
pos_tmp = positions.pop(-1)
area_tmp = h_tmp * (j - pos_tmp)
if area_tmp > max_area:
max_area = area_tmp
pos_at_max_area = (pos_tmp,i) #this is the bottom left
height_at_max_area = h_tmp
x_end = j
heights.append(h)
positions.append(pos_tmp)
while len(heights) > 0:
h_tmp = heights.pop(-1)
pos_tmp = positions.pop(-1)
area_tmp = h_tmp * (j - pos_tmp)
if area_tmp > max_area:
max_area = area_tmp
pos_at_max_area = (pos_tmp,i) #this is the bottom left
height_at_max_area = h_tmp
x_end = j

top_left = (int(pos_at_max_area[0]),int(pos_at_max_area[1] - height_at_max_area) + 1)
width = int(x_end - pos_at_max_area[0])
height = int(height_at_max_area - 1)

For the input image, you can threshold all of the non-zero values with `(stk > 0).astype('uint8')` and do a minimum projection of your timeseries using `np.min(stk,axis=0)`. Be sure to fill in any holes using `scipy.ndimage.morphology.binary_fill_holes`.
